The 4EES-6Y-EE is a premium Semi Hermetic Condensing Unit engineered by KUB Refrigeration Equipment Co., Ltd, designed to deliver exceptional cooling performance for commercial and industrial cold storage applications. This unit integrates a high-efficiency semi hermetic reciprocating compressor with a perfectly matched air-cooled condenser, providing a compact yet powerful refrigeration solution.
Manufactured in Shanghai, China, with over 20 years of refrigeration engineering expertise, the 4EES-6Y-EE combines advanced compressor technology with robust construction to ensure long-term reliable operation. Every unit undergoes rigorous factory testing including pressure tests, electrical safety checks, and performance validation before shipment.
| Parameter | Specification |
|---|---|
| Model | 4EES-6Y-EE |
| Compressor Type | Semi Hermetic Reciprocating |
| Horsepower | 6HP |
| Cylinders | 4 |
| Displacement | 22.7 m³/h |
| COP Rating | ≥ 1.8 |
| Power Supply | 380V/3PH/50Hz |
| Evaporating Temp Range | -25°C to +5°C |
| Cooling Capacity @ -25°C | 5240W |
| Cooling Capacity @ -15°C | 8390W |
| Refrigerant | R22 / R404a / R134a |
| Condenser Type | Air Cooled Finned |
| Number of Fans | 2 * 400mm Axial |
| Suction Line | 28mm (1-1/8") |
| Liquid Line | 12mm (1/2") |
| Net Weight | 205kg |
| Dimensions (L*W*H) | 1300 * 750 * 770mm |
| Oil Type | B5.2 Refrigeration Oil |
| Certification | CE |
| Warranty | 1 Year |
Recommended for medium-temperature cold rooms, refrigerated warehouses, dairy and beverage storage, fruit and vegetable preservation, and cost-sensitive operations where energy savings directly impact the bottom line.
